3000 Series

$0.00

This product has all the characteristics of the 3000 Series, but is designed to hold up to twice the overspray before changing is required. This double service life makes this series ideal for high production applications and wherever a large volume of coating is applied in a relatively small booth space. This longer service life results in less down time, fewer changeovers and greater economy. Rolls or pads are used in tandem. The product is ideal for heavy, tacky coatings or slower drying finishes, but it is not recommended for quick dry lacquer type coatings.

PAINT ARRESTOR IDENTIFICATION

PA Model: 3000 Series Spra-Gard High Efficiency RP Paint Arrestor

RP Part #: 3032 Single Layer (20”x20”)

Number of pads in series: 2

TEST INFORMATION

Paint Description: High Solids Baking Enamel (S.W. #1 Permaclad 2400, red)

Paint Spray Method: Conventional Air Gun at 40 PSI

Spray Feed Rate: 143 grains/min. 135 cc./min.

Air Velocity: 150 FPM

TEST RESULTS

Initial Pressure Drop of Clean Test Filter: 0.03 in. wg

Final Pressure Drop of Loaded Test Filter: 0.27 in. wg

Paint Holding Capacity of Test Filter: 2244 grams = 4.9 lb.

Average Removal Efficiency of Test Filter: 99.22%

Life is too short to live without the 3000 Series. Be happy. Be Content. Be Satisfied.

Inventory Last Updated: Mar 28, 2024
