Spra-Cube UE

$0.00

The RP Spra-Cube extended surface cubes are the latest in RP’s storied line of high-efficiency spray booth filters. Each cube is designed to provide high holding capacity and an economical solution for a range of finishing applications. All Spra-Cube filters are constructed of multiple layers of RP’s proprietary paper Paint Arrestor media and synthetic backings to provide you the right product, every time.

PAINT ARRESTOR IDENTIFICATION

PA Model: Series UE Ultra Efficiency High Holding Capacity

RP Part #: 2 Pockets RP Cube (v.3) (20”x20”x15”)

TEST INFORMATION

Paint Description: High Solids Baking Enamel (S.W. #1 Permaclad 2400, red)

Paint Spray Method: Conventional Air Gun at 40 PSI

Spray Feed Rate: 143 grains/min. 135 cc./min.

Air Velocity: 150 FPM

TEST RESULTS

Initial Pressure Drop of Clean Test Filter: 0.05 in. wg

Final Pressure Drop of Loaded Test Filter: 0.09 in. wg

Paint Holding Capacity of Test Filter: 3798 grams = 8.4 lb.

Average Removal Efficiency of Test Filter: 99.48%
